Data about Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01
We were unable to add 'Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01' to your cart as it is currently out of stock.
SKU: 18348N_NTG-1
Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01
In Stock
We were unable to add 'Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01' to your cart as it is currently out of stock.
SKU: 18348N_NTG-1
Compatible With:
Yamaha Outboard Engine
F50TLR 2005-2008
F60TJR 2005-2008
F60TLR 2005-2008
F90TJR 2005-2008
F90TLR 2005-2008
F90TXR 2005-2008
LZ150TR 2000
LZ150TXR 2000-2006
LZ200TR 2000
LZ200TXR 2000-2013
T50TLR 2005-2008
T60TLR 2005-2008
VZ150TLR 2000-2015
VZ175TLR 2001-2013
VZ200TLR 2001-2004
Z150TLR 2000-2004
Z150TR 2000
Z150TXR 2000-2006
Z175TXR 2001-2006
Z200TLR 2000-2006
Z200TR 2000
Z200TXR 2000-2013
Specifications:
Type: PMGR
Voltage: 12 Volts
Rotation: CCW
Teeth/Splines: 13 Teeth/Splines
Pinion/Splines OD: 39.7mm / 1.563in
Mounting Hole 1: 8.8mm ID Unthreaded
Mounting Hole 2: 8.8mm ID Unthreaded
Approximate Weight: 8.1 lbs / 3.68 kg
Notes:
63cm Switch Lead
6.6mm ID Ring Terminal
Battery Stud M8-1.25 Threaded
Replaces OEM Part Numbers:
API Marine: MOT5018
Arco Marine: 3431
Hitachi: S114-836A, S114-836BN, S114-916, S114-916A, S114-916B
Mercury Marine: 8M6007429
Remy Small Motor: RS41166
Sierra Marine: 18-6426
Yamaha: 68F-81800-00, 68F81800-00, 68F-81800-01, 68F81800-01, 68F-81800-02, 68F81800-02
Specification
Description
Compatible With:
Yamaha Outboard Engine
F50TLR 2005-2008
F60TJR 2005-2008
F60TLR 2005-2008
F90TJR 2005-2008
F90TLR 2005-2008
F90TXR 2005-2008
LZ150TR 2000
LZ150TXR 2000-2006
LZ200TR 2000
LZ200TXR 2000-2013
T50TLR 2005-2008
T60TLR 2005-2008
VZ150TLR 2000-2015
VZ175TLR 2001-2013
VZ200TLR 2001-2004
Z150TLR 2000-2004
Z150TR 2000
Z150TXR 2000-2006
Z175TXR 2001-2006
Z200TLR 2000-2006
Z200TR 2000
Z200TXR 2000-2013
Specifications:
Type: PMGR
Voltage: 12 Volts
Rotation: CCW
Teeth/Splines: 13 Teeth/Splines
Pinion/Splines OD: 39.7mm / 1.563in
Mounting Hole 1: 8.8mm ID Unthreaded
Mounting Hole 2: 8.8mm ID Unthreaded
Approximate Weight: 8.1 lbs / 3.68 kg
Notes:
63cm Switch Lead
6.6mm ID Ring Terminal
Battery Stud M8-1.25 Threaded
Replaces OEM Part Numbers:
API Marine: MOT5018
Arco Marine: 3431
Hitachi: S114-836A, S114-836BN, S114-916, S114-916A, S114-916B
Mercury Marine: 8M6007429
Remy Small Motor: RS41166
Sierra Marine: 18-6426
Yamaha: 68F-81800-00, 68F81800-00, 68F-81800-01, 68F81800-01, 68F-81800-02, 68F81800-02
At a Glance
| Brand | Nth Gear |
|---|---|
| Part # / SKU | 18348N_NTG-1 |
Product Data Sheets
Downloads and manuals associated to Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01
Available Variants
Different variants associated to the Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01
-
$104.61
- In Stock
-
Link Copied!
- SKU:
- 18348N_NTG-1
- UPC:
Frequently Asked Questions
What vehicles is Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01 compatible with?+
Use the specifications and images on this page together with your vehicle details. Match part number 18348N_NTG-1 to your existing component or OEM interchange.
Explore similar Parts and Accessories to find the right fit for your car, truck, SUV, or powersports vehicle. See more Nth Gear products we carry.
What is Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01 used for?+
Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01 from Nth Gear is intended for normal automotive service and maintenance—such as brake pad and rotor service, oil and filter changes, or other listed applications—depending on how this SKU is categorized. Follow your owner’s manual and any torque or fluid specs printed on the packaging.
Discover complementary items in our Parts and Accessories collection and Starters.
Is this Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01 an OEM or aftermarket part?+
This listing is an aftermarket replacement manufactured or branded by Nth Gear, engineered to meet or exceed typical OEM performance for the applications described. It is not necessarily a dealer-original part unless the description states otherwise.
Compare alternatives in Parts and Accessories if you need a different formulation, kit, or price point.
What is included with Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01?+
You receive the Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01 (SKU / part number 18348N_NTG-1) as shown in the photos and bullet points. Kits may include filters, gaskets, hardware, or fluids; single components include only that item. Open the Specifications and Includes areas on this page to confirm quantity and contents.
How do I install Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01?+
Installation steps depend on the part type (for example, brake pads versus an oil change kit). Work on a cool vehicle, use proper jack stands and tools, torque fasteners to spec, and bed brakes or prime filters per the manufacturer’s instructions. If you are not experienced with suspension or brake work, use a licensed technician.
Find related service items in Parts and Accessories. You may also consider Starter Fits Yamaha Personal Watercraft & Sportboats 6S5-81800-00-00 8M6007432 or Starter Fits Yamaha RX10 Snowmobiles 8FP81890-00-00, 8HG-81890-00-00.
What warranty or return policy applies to Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01?+
New, uninstalled items are generally eligible for return within the time window posted in our store policies, provided they are in resalable condition. Reference your order and SKU 18348N_NTG-1 when contacting support. Defective or incorrect shipments should be reported promptly with photos when possible.
Need a different fitment? Browse Parts and Accessories for other compatible options.
How long does shipping take and when will Starter Fits Yamaha Outboard Engines 68F-81800-00, 68F81800-00, 68F-81800-01 be available?+
Many in-stock orders ship the same business day when placed before the warehouse cutoff. Transit usually takes about 2–5 business days in the contiguous U.S., depending on carrier and destination. Availability is shown near the add-to-cart button on this page.
Shop additional in-stock choices in Parts and Accessories.
How do I double-check that this part fits my vehicle?+
Cross-check year, make, model, engine, and trim with the fitment data on this page, your old part number, and SKU 18348N_NTG-1. When in doubt, verify with a dealer parts catalog or qualified mechanic before opening packaging.
Similar listings: Starter Fits Yamaha Personal Watercraft & Sportboats 6S5-81800-00-00 8M6007432 and Starter Fits Yamaha RX10 Snowmobiles 8FP81890-00-00, 8HG-81890-00-00. Explore the full Parts and Accessories category for oil change kits, brake parts, filters, and more.
