Data about Starter For Isuzu C190 C240 4JB1 Engines, TCM FD23Z FD25Z Lift Trucks 8944234520
We were unable to add 'Starter For Isuzu C190 C240 4JB1 Engines, TCM FD23Z FD25Z Lift Trucks 8944234520' to your cart as it is currently out of stock.
SKU: 18281N_NTG-1
Starter For Isuzu C190 C240 4JB1 Engines, TCM FD23Z FD25Z Lift Trucks 8944234520
In Stock
We were unable to add 'Starter For Isuzu C190 C240 4JB1 Engines, TCM FD23Z FD25Z Lift Trucks 8944234520' to your cart as it is currently out of stock.
SKU: 18281N_NTG-1
Compatible With:
Isuzu Engines - Industrial
Misc. Industrial Equipment C-190 Engine 1982-1995
Misc. Industrial Equipment C-240 Engine 1982-1995
Misc. Industrial Equipment 4JB1 Engine 1995-2000
TCM Equipment Lift Truck
FD23Z Isuzu C240 Diesel 1978-1997
FD25Z Isuzu C240 Diesel 1978-1997
Specifications:
Volt: 24
Power: 3.500 kw
HP: 4.694
Rotation Direction: Clockwise
Electric Starter Type: Offset Gear Reduction (OSGR)
Number of Teeth: 9
Gear OD: 1.280"/32.500mm
Length: 224.500 mm/8.839"
Mount Hole ID 1: 13mm Unthreaded
Mount Hole 2 Type: Unthreaded
Registry OD: 3.740"/95mm
Notes: M8-1.25 B+ & Motor Terminals @M4-0.7 Threaded S Terminal
Mounting Ear Distance 1: 119.500mm/4.705"
Replaces OEM Part Numbers:
Delco: DRS0517
Hitachi: S24-07
Isuzu: 8944234520
Lester: 18281
Specification
Description
Compatible With:
Isuzu Engines - Industrial
Misc. Industrial Equipment C-190 Engine 1982-1995
Misc. Industrial Equipment C-240 Engine 1982-1995
Misc. Industrial Equipment 4JB1 Engine 1995-2000
TCM Equipment Lift Truck
FD23Z Isuzu C240 Diesel 1978-1997
FD25Z Isuzu C240 Diesel 1978-1997
Specifications:
Volt: 24
Power: 3.500 kw
HP: 4.694
Rotation Direction: Clockwise
Electric Starter Type: Offset Gear Reduction (OSGR)
Number of Teeth: 9
Gear OD: 1.280"/32.500mm
Length: 224.500 mm/8.839"
Mount Hole ID 1: 13mm Unthreaded
Mount Hole 2 Type: Unthreaded
Registry OD: 3.740"/95mm
Notes: M8-1.25 B+ & Motor Terminals @M4-0.7 Threaded S Terminal
Mounting Ear Distance 1: 119.500mm/4.705"
Replaces OEM Part Numbers:
Delco: DRS0517
Hitachi: S24-07
Isuzu: 8944234520
Lester: 18281
At a Glance
| Brand | Nth Gear |
|---|---|
| Part # / SKU | 18281N_NTG-1 |
